Performance Upgrades Fueled by Contributions from Xiaomi Engineers

June 24 2025Solutions

Loïc Mathieu

Lead Developer

Table of Contents

OVERVIEW

Plugins have a Min. Compatible Kestra Version i.e. a Kestra version from where the corresponding plugin version is compatible. Learn more

Created by

Kestra Core Team

Managed by

Kestra Core Team

Table of Contents

Contribute

In 0.22, the engineering team focused on performance in multiple areas, you can find the details in this blog post Optimizing Performance in Kestra in Version 0.22.

One of our most advanced power users, the Xiaomi Engineering team, extensively leverages Kestra at a massive scale. Xiaomi’s continuous insights and active contributions have significantly accelerated our performance optimization efforts in Kestra 0.23. Thanks to their help, this latest version delivers even more substantial enhancements in speed, efficiency, and system responsiveness.

Smarter Output Processing

The Kestra Executor merges task outputs, enabling subsequent tasks to access previous outputs through our expression language. Historically, this merging process involved cloning the entire output map, consuming significant CPU and memory resources.

In Kestra 0.22, we limited merges exclusively to tasks that explicitly required it, notably improving efficiency. Kestra 0.23 further refines this process by:

• Avoiding unnecessary merges for empty task outputs.

• Enhancing iterative output merging methods.

For example, a workflow with 160 loop iterations improved dramatically from 44 seconds down to just 13 seconds.

id: hummingbird_941521
namespace: company.team

tasks:

  - id: foreach
    type: io.kestra.plugin.core.flow.ForEach
    values: "{{range(1, 160)}}"
    concurrencyLimit: 0
    tasks:
      - id: log
        type: io.kestra.plugin.core.log.Log
        message: Some log

This was the happy case, when there are no outputs, using the same flow with the OutputValues task instead of the Log task will still bring an enhancement from 44s to 24s.

Further details are available in these two pull requests: PR #8914 and PR #8911

Flowable task processing improvements

Flowable tasks provide the orchestration logic of Kestra; they are run by the Executor, not the Worker.

Historically, for simplicity, we mimicked task execution by the Worker for all flowable tasks, unnecessarily adding them to our internal queue, causing redundant overhead. Kestra 0.23 now directly records flowable task results within the Executor, significantly reducing overhead.

Further details can be found in this pull request: PR #8236.

Let’s take as an example this flow that has 5 If tasks, the If task is flowable:

id: bench-flowable
namespace: company.team

inputs:
  - id: condition
    type: BOOL
    defaults: true

triggers:
  - id: webhook
    type: io.kestra.plugin.core.trigger.Webhook
    key: webhook

tasks:
  - id: if1
    type: io.kestra.plugin.core.flow.If
    condition: "{{inputs.condition}}"
    then:
    - id: hello-true-1
      type: io.kestra.plugin.core.log.Log
      message: Hello True 1
    else:
    - id: hello-false-1
      type: io.kestra.plugin.core.log.Log
      message: Hello False 1
  - id: if2
    type: io.kestra.plugin.core.flow.If
    condition: "{{inputs.condition}}"
    then:
    - id: hello-true-2
      type: io.kestra.plugin.core.log.Log
      message: Hello True 2
    else:
    - id: hello-false-2
      type: io.kestra.plugin.core.log.Log
      message: Hello False 2
  - id: if1-3
    type: io.kestra.plugin.core.flow.If
    condition: "{{inputs.condition}}"
    then:
    - id: hello-true-3
      type: io.kestra.plugin.core.log.Log
      message: Hello True 3
    else:
    - id: hello-false-3
      type: io.kestra.plugin.core.log.Log
      message: Hello False 3
  - id: if4
    type: io.kestra.plugin.core.flow.If
    condition: "{{inputs.condition}}"
    then:
    - id: hello-true-4
      type: io.kestra.plugin.core.log.Log
      message: Hello True 4
    else:
    - id: hello-false-4
      type: io.kestra.plugin.core.log.Log
      message: Hello False 4
  - id: if5
    type: io.kestra.plugin.core.flow.If
    condition: "{{inputs.condition}}"
    then:
    - id: hello-true-5
      type: io.kestra.plugin.core.log.Log
      message: Hello True 5
    else:
    - id: hello-false-5
      type: io.kestra.plugin.core.log.Log
      message: Hello False 5

In high-load scenarios (e.g., 10 executions per second), performance improved dramatically, reducing execution times from 12 seconds per task in 0.22 to just 4 seconds in 0.23.

Missing indices on the JDBC backend

Thanks to user feedback, we discovered that we missed some indices on tables on our JDBC backend.

The service_instance table was missing a few indices and a purge mechanism! We added both, and queries on this table show no longer an issue. This table monitors Kestra services’ liveness and is queried periodically by all the Kestra components. See PR #8319 and PR #8505 which were contributions from lw-yang from Xiaomi.

The queues table, which is the heart of our internal queue, was missing an index on the key column, which has been used since 0.22 to purge queue messages at the end of an execution. We added one in 0.23; see PR #8243.

Outstanding Scheduler improvements from Xiaomi

Wei Bo from Xiaomi significantly contributed two major improvements to our JDBC Scheduler:

• A missing index on the next_execution_date column of the triggers table, which drastically accelerates scheduler evaluation times. See PR #8387.
• A huge enhancement that extracts triggered execution monitoring from the main scheduler evaluation loop, dramatically improving efficiency. Before this change, the evaluation loop could take as long as 1 minute under heavy workloads. With Xiaomi’s contribution, the execution time plummeted to just 40 milliseconds! See PR #8741.

The latter enhancement, championed by Xiaomi, represents a leap forward in performance. Previously, the Kestra Scheduler ran a single evaluation loop every second, performing various tasks—from checking triggers’ next execution dates to verifying pending executions and logging warnings. While crucial, these monitoring checks unnecessarily slowed down the main loop, severely impacting performance in large-scale scenarios like those experienced at Xiaomi.

Xiaomi’s engineering team re-engineered the scheduler by introducing a dedicated monitoring loop. This separation improved efficiency and responsiveness. Xiaomi’s benchmarks at their massive scale showed a remarkable decrease in loop execution time, from roughly 1 minute down to an astonishing 40 milliseconds!

This breakthrough is especially impactful in large-scale deployments. If a scheduler loop exceeds 1 second, scheduled triggers could be missed entirely, severely impacting operational reliability. For instance, imagine polling a database every 10 seconds: if scheduler evaluations took longer than intended, the trigger frequency would be compromised.

Xiaomi tackled these issues head-on, contributing profoundly to Kestra’s capabilities. We extend our deepest appreciation to Wei Bo and the entire Xiaomi Engineering team, whose detailed feedback and substantial contributions continue to improve Kestra’s performance benchmarks.

Changed the way we parallelized JDBC Backend Queues

In 0.22, we parallelized JDBC Backend queues processing by the Kestra executor, which brings tremendous performance improvements, but with a caveat of way bigger memory usage and high load on the database.

In 0.23, we changed the way we parallelized JDBC Backend queues processing. Instead of querying the database multiple times in parallel, we made a single query but processed the query results in parallel. See PR #8648

We then made slight improvements to our queue polling mechanism, improving high-throughput performance. See PR #8840 and PR #8263.

These changes slightly decrease performance on low throughput but have an overall neutral performance with a net benefit on memory usage and database load.

Conclusion

Version 0.23 brings major upgrades in performance and scalability, thanks in no small part to the Xiaomi Engineering team. Their production-scale usage, diagnostics, and highly targeted contributions, like the scheduler improvements, continue to shape how Kestra evolves.

We’re incredibly grateful for their collaboration and the broader open-source community, which make Kestra better with every release. As Xiaomi pushes the platform to its limits, they help us unlock new levels of efficiency for everyone.

Stay tuned—there’s even more to come as we double down our focus on performance, resiliency, and scalability.
