Curated Examples to Help You Build with Kestra

Explore our curated library of Blueprints to help you build with Kestra.

When you get started with a new tool, it can be overwhelming to know where to start and what to look at first. You probably already have some existing code that you’re looking to integrate without doing a ton of extra work.

If you’re anything like me, the first thing I like to do when using a new tool for the first time is look for some examples that I can modify to suit my needs, which is why we’ve build a library of curated examples called Blueprints to enable this. We’ll walk through a number of our Blueprints that cover common scenarios to help you identify where you should start!

As a unified orchestrator, Kestra can handle almost any use case. With this in mind, we’re going to discuss some of the common building blocks to enable you to build something that fits your use case:

How to get your code set up and running in Kestra.
Automating that by pulling new changes automatically from our Git repository.
Tapping into the cloud for more resources to expand our current logic.
Alerts and how we can configure alerts for our workflow.

With all these combined, we can build powerful workflows. Let’s look at some Blueprints for each of these areas.

Integrating Your Code into Kestra

One of the main questions we get is, ‘how do I get my code into Kestra?’ Don’t worry, we’ve got you covered. We recently did an in-depth article on how to integrate your code directly into Kestra, including handling inputs, outputs and files to allow Kestra to work best with your code.

To accompany that, we’ve got a number of helpful Blueprints covering a variety of use cases.

Data Engineering Pipeline Example

Starting off, this flow demonstrates a data engineering pipeline utilizing Python. As each task generates outputs, we can access those in later tasks allowing everything to work in unison. This example works straight out of the box, so you can jump into Kestra and give it a go yourself.

id: data-engineering-pipeline
namespace: tutorial
description: Data Engineering Pipelines
inputs:
  - id: columns_to_keep
    type: ARRAY
    itemType: STRING
    defaults:
      - brand
      - price
tasks:
  - id: extract
    type: io.kestra.plugin.core.http.Download
    uri: https://dummyjson.com/products
  - id: transform
    type: io.kestra.plugin.scripts.python.Script
    containerImage: python:3.11-alpine
    inputFiles:
      data.json: "{{ outputs.extract.uri }}"
    outputFiles:
      - "*.json"
    env:
      COLUMNS_TO_KEEP: "{{ inputs.columns_to_keep }}"
    script: |
      import json
      import os

      columns_to_keep_str = os.getenv("COLUMNS_TO_KEEP")
      columns_to_keep = json.loads(columns_to_keep_str)

      with open("data.json", "r") as file:
          data = json.load(file)

      filtered_data = [
          {column: product.get(column, "N/A") for column in columns_to_keep}
          for product in data["products"]
      ]

      with open("products.json", "w") as file:
          json.dump(filtered_data, file, indent=4)
  - id: query
    type: io.kestra.plugin.jdbc.duckdb.Query
    inputFiles:
      products.json: "{{ outputs.transform.outputFiles['products.json'] }}"
    sql: |
      INSTALL json;
      LOAD json;
      SELECT brand, round(avg(price), 2) as avg_price
      FROM read_json_auto('{{ workingDir }}/products.json')
      GROUP BY brand
      ORDER BY avg_price DESC;
    store: true

Check out the Blueprint here.

Run C code inside of a Shell environment

In this next example, we can see the power of Kestra being language agnostic coming into action. We’re able to utilize the Shell Commands task to give us an environment to run any language, as long as we install the required dependencies. In this scenario, we’re using a gcc container image to set up our Shell environment for C. Another neat thing with this example is the ability to dynamically set the dataset_url at execution without needing to touch the code directly.

id: shell-execute-code
namespace: company.team

inputs:
  - id: dataset_url
    type: STRING
    defaults: https://huggingface.co/datasets/kestra/datasets/raw/main/csv/orders.csv

tasks:
  - id: download_dataset
    type: io.kestra.plugin.core.http.Download
    uri: "{{ inputs.dataset_url }}"
  - id: c_code
    type: io.kestra.plugin.scripts.shell.Commands
    taskRunner:
      type: io.kestra.plugin.scripts.runner.docker.Docker
    containerImage: gcc:latest
    commands:
      - gcc example.c
      - ./a.out
    inputFiles:
      orders.csv: "{{ outputs.download_dataset.uri }}"
      example.c: |
        #include <stdio.h>
        #include <stdlib.h>
        #include <string.h>

        int main() {
            FILE *file = fopen("orders.csv", "r");
            if (!file) {
                printf("Error opening file!\n");
                return 1;
            }

            char line[1024];
            double total_revenue = 0.0;

            fgets(line, 1024, file);
            while (fgets(line, 1024, file)) {
                char *token = strtok(line, ",");
                int i = 0;
                double total = 0.0;

                while (token) {
                    if (i == 6) {
                        total = atof(token);
                        total_revenue += total;
                    }
                    token = strtok(NULL, ",");
                    i++;
                }
            }

            fclose(file);
            printf("Total Revenue: $%.2f\n", total_revenue);

            return 0;
        }

Check out the Blueprint here

Access Your Git repositories Inside of Your Workflows

Orchestrating your code is useful, but being able to sync that with your Git repository streamlines it even more. There are multiple ways to integrate with Git inside of Kestra:

Clone
PushFlows/SyncFlows and PushNamespaceFiles/SyncNamespaceFiles

Clone a GitHub repository and run a Python ETL script

Starting with Clone, we can clone our repository and then have other tasks access it as if we were using it on our local machine.

This example also uses the WorkingDirectory task to create an environment where we can write files and easily access them between tasks. Without this, we’d have to pass them between tasks as [output files]((../../docs/16.scripts/input-output-files.md), which can become tedious for larger outputs, like a repository. This means we’re always using the most up to date code when we run this workflow.

id: git-python
namespace: company.team

tasks:
  - id: python_scripts
    type: io.kestra.plugin.core.flow.WorkingDirectory
    tasks:
      - id: clone_repository
        type: io.kestra.plugin.git.Clone
        url: https://github.com/kestra-io/scripts
        branch: main
      - id: python
        type: io.kestra.plugin.scripts.python.Commands
        warningOnStdErr: false
        taskRunner:
          type: io.kestra.plugin.scripts.runner.docker.Docker
        containerImage: ghcr.io/kestra-io/pydata:latest
        commands:
          - python etl/global_power_plant.py

Check out the Blueprint here

Sync code from Git at regular intervals

This example uses the SyncFlows and SyncNamespaceFiles to pull the content of our Git repository directly into Kestra, rather than isolated inside of a flow. This is useful for managing our Kestra instance, especially if we have separate dev and production instances. You could also swap the Schedule trigger for a Webhook trigger that triggers when new changes are in your main branch.

id: sync-from-git
namespace: company.team

tasks:
  - id: sync_flows
    type: io.kestra.plugin.git.SyncFlows
    gitDirectory: flows
    targetNamespace: git
    includeChildNamespaces: true
    delete: true
    url: https://github.com/kestra-io/flows
    branch: main
    username: git_username
    password: "{{ secret('GITHUB_ACCESS_TOKEN') }}"
    dryRun: true
  - id: sync_namespace_files
    type: io.kestra.plugin.git.SyncNamespaceFiles
    namespace: prod
    gitDirectory: _files
    delete: true
    url: https://github.com/kestra-io/flows
    branch: main
    username: git_username
    password: "{{ secret('GITHUB_ACCESS_TOKEN') }}"
    dryRun: true

triggers:
  - id: every_full_hour
    type: io.kestra.plugin.core.trigger.Schedule
    cron: "*/15 * * * *"

Check out the Blueprint here

Tap into the Power of the Cloud

Another common use case is integrating Kestra directly with the cloud. It’s no mystery that cloud providers can unlock tons of possibilities with their huge amount of compute power.

We have official plugins for AWS, Google Cloud and Azure which cover all aspects of the platforms. Let’s jump into a few different examples that allow you to integrate your code with them using Kestra.

Detect New Files in S3 and process them in Python

Jumping right in, this workflow is event driven based on files arriving in an S3 bucket using the S3 Trigger. This is a great way to allow Kestra to make your existing code event driven.

id: s3-trigger-python
namespace: company.team

variables:
  bucket: s3-bucket
  region: eu-west-2

tasks:
  - id: process_data
    type: io.kestra.plugin.scripts.python.Commands
    taskRunner:
      type: io.kestra.plugin.scripts.runner.docker.Docker
    containerImage: ghcr.io/kestra-io/kestrapy:latest
    namespaceFiles:
      enabled: true
    inputFiles:
      input.csv: "{{ read(trigger.objects[0].uri) }}"
    outputFiles:
      - data.csv
    commands:
      - python process_data.py

triggers:
  - id: watch
    type: io.kestra.plugin.aws.s3.Trigger
    interval: PT1S
    accessKeyId: "{{ secret('AWS_ACCESS_KEY_ID') }}"
    secretKeyId: "{{ secret('AWS_SECRET_KEY_ID') }}"
    region: "{{ vars.region }}"
    bucket: "{{ vars.bucket }}"
    filter: FILES
    action: MOVE
    moveTo:
      key: archive/
    maxKeys: 1

Check out the Blueprint here

Use GCP Pub/Sub Realtime Trigger to push events into Firestore

On the trend of event driven workflows, we can use Realtime triggers to allow our workflows to react to new messages with low latency.

In this example, we’re using the Google Cloud PubSub Realtime Trigger to listen for new messages in realtime, and setting that data in a Firestore database.

id: pubsub-realtime-trigger
namespace: company.team

tasks:
  - id: insert_into_firestore
    type: io.kestra.plugin.gcp.firestore.Set
    projectId: test-project-id
    collection: orders
    document:
      order_id: "{{ trigger.data | jq('.order_id') | first }}"
      customer_name: "{{ trigger.data | jq('.customer_name') | first }}"
      customer_email: "{{ trigger.data | jq('.customer_email') | first }}"
      product_id: "{{ trigger.data | jq('.product_id') | first }}"
      price: "{{ trigger.data | jq('.price') | first }}"
      quantity: "{{ trigger.data | jq('.quantity') | first }}"
      total: "{{ trigger.data | jq('.total') | first }}"

triggers:
  - id: realtime_trigger
    type: io.kestra.plugin.gcp.pubsub.RealtimeTrigger
    projectId: test-project-id
    topic: orders
    subscription: kestra-subscription
    serdeType: JSON

Check out the Blueprint here

Run a Python script on Azure with Azure Batch VMs

In our last cloud example, we can easily execute our code directly on cloud resources using Task Runners.

This example uses the Azure Batch to execute our Python code, and then returns all outputs back to Kestra, enabling us to use more resources on demand.

id: azure-batch-runner
namespace: company.team

variables:
  pool_id: poolId
  container_name: containerName

tasks:
  - id: scrape_environment_info
    type: io.kestra.plugin.scripts.python.Commands
    containerImage: ghcr.io/kestra-io/pydata:latest
    taskRunner:
      type: io.kestra.plugin.ee.azure.runner.Batch
      account: "{{ secret('AZURE_ACCOUNT') }}"
      accessKey: "{{ secret('AZURE_ACCESS_KEY') }}"
      endpoint: "{{ secret('AZURE_ENDPOINT') }}"
      poolId: "{{ vars.pool_id }}"
      blobStorage:
        containerName: "{{ vars.container_name }}"
        connectionString: "{{ secret('AZURE_CONNECTION_STRING') }}"
    commands:
      - python {{ workingDir }}/main.py
    namespaceFiles:
      enabled: true
    outputFiles:
      - environment_info.json
    inputFiles:
      main.py: >
        import platform
        import socket
        import sys
        import json
        from kestra import Kestra

        print("Hello from Azure Batch and kestra!")

        def print_environment_info():
            print(f"Host's network name: {platform.node()}")
            print(f"Python version: {platform.python_version()}")
            print(f"Platform information (instance type): {platform.platform()}")
            print(f"OS/Arch: {sys.platform}/{platform.machine()}")

            env_info = {
                "host": platform.node(),
                "platform": platform.platform(),
                "OS": sys.platform,
                "python_version": platform.python_version(),
            }
            Kestra.outputs(env_info)

            filename = 'environment_info.json'
            with open(filename, 'w') as json_file:
                json.dump(env_info, json_file, indent=4)

        if __name__ == '__main__':
          print_environment_info()

Check out the Blueprint here

Add Alerts to Your Workflows

One of the benefits of Kestra is being able to integrate your code straight away, and build automated alerting around it. Let’s take a look at a few examples of alerting in Kestra.

Send a Slack message via incoming webhook

With this simple workflow, we can easily add this to any of our workflows, and incorporate data generated by tasks using expressions.

id: slack-incoming-webhook
namespace: company.team

tasks:
  - id: slack
    type: io.kestra.plugin.slack.SlackIncomingWebhook
    url: "{{ secret('SLACK_WEBHOOK') }}"
    payload: >
      {
        "channel": "#alerts",
        "text": "Flow {{ flow.namespace }}.{{ flow.id }} started with execution {{ execution.id }}"
      }

Check out the Blueprint here

Set up alerts for failed workflow executions using Discord

This next example is a System flow which are useful for maintaining our Kestra instance. Using a Flow Trigger, we can send automated messages to Discord every time a workflow finishes with FAILED or WARNING state. Useful to give you real time information at your finger tips.

id: failure-alert-discord
namespace: system

tasks:
  - id: send_alert
    type: io.kestra.plugin.discord.DiscordExecution
    url: "{{ secret('DISCORD_WEBHOOK') }}"
    executionId: "{{ trigger.executionId }}"

triggers:
  - id: on_failure
    type: io.kestra.plugin.core.trigger.Flow
    conditions:
      - type: io.kestra.plugin.core.condition.ExecutionStatus
        in:
          - FAILED
          - WARNING

Check out the Blueprint here

What’s next?

This is just the start of some of the areas you can explore in Kestra to integrate into your existing solution. I’d recommend checking out the full Blueprint library for over 180 curated examples. If you build any useful examples, feel free to contribute back by making a Pull Request on our GitHub repository!

If you like the project, give us a GitHub star ⭐️ and join the community.

If you have any questions, reach out via Slack or open a GitHub issue.
