Flows can have Input. They are parameters provided when starting a flow. They help make your flow more dynamic and reusable.
Defining inputs
We defined Inputs in the inputs section of the flow file. They must have a name and a type.
You can also set a default value.
yaml
inputs:
- name: isTutorial
type: BOOLEAN
default: true| Type | Description |
|---|---|
| STRING | No control is done on this input type (no parsing), can be any string. |
| INT | Must be a valid integer (without any decimals). |
| BOOLEAN | Must be a valid true or false as string. |
Discover more types on the input documentation.
Accessing inputs
Kestra includes a templating engine to access variables in your flow. Use the {{ variable }} syntax to access them.
Find more on the variable documentation.
Inputs can be accessed in the flow using the {{ inputs.name }} syntax.
Add inputs to your flow
In our example, we will provide the URL of the CSV file we want to download in Input. But we will set a default value if the user doesn't provide it.
yaml
inputs:
- name: url
type: STRING
default: "https://gist.githubusercontent.com/tchiotludo/2b7f28f4f507074e60150aedb028e074/raw/6b6348c4f912e79e3ffccaf944fd019bf51cba30/conso-elec-gaz-annuelle-par-naf-agregee-region.csv"Click here to see the full flow
yaml
id: kestra-tutorial
namespace: io.kestra.tutorial
labels:
env: PRD
description: |
# Kestra Tutorial
As you notice, we can use markdown here.
inputs:
- name: url
type: STRING
default: "https://gist.githubusercontent.com/tchiotludo/2b7f28f4f507074e60150aedb028e074/raw/6b6348c4f912e79e3ffccaf944fd019bf51cba30/conso-elec-gaz-annuelle-par-naf-agregee-region.csv"
tasks:
- id: download
type: io.kestra.plugin.fs.http.Download
uri: "{{ inputs.url }}"
